pneumatic coil nailer for making wooden doors and windows

Compared to traditional coil nailers, pneumatic coil nailers are able to hold more nails, reducing the time it takes to frequently refill nails and increasing work efficiency.

Technical Parameters of Pneumatic Coil Nailer

• Order No.: CN90
• Weight: 3.8kg
• Size: 142x408x410mm
• Number of nails: 300
• Air pressure: 6 to 8kg/cm²
• Tube diameter: 8mm

Features of Pneumatic Coil Nailer

1. High performance: Pneumatic drive, providing strong nailing force, suitable for all kinds of hardness of wood, to ensure that the nails are firmly nailed.
2. Large-capacity nail loading: Equipped with roll nailing system, it can load a large number of nails at one time, which reduces the frequency of adding nails and is suitable for mass production.


3. Adjustable Nail Depth: Through the adjusting device, users can set the depth of nail driving according to the thickness and hardness of different materials to ensure the fixing effect.
4. Comfortable operation: Ergonomic design, moderate weight, non-slip handle, not easy to fatigue in long time operation.
5. Safety design: Equipped with a safety trigger mechanism to prevent misoperation, and also has an anti-empty strike function to ensure that no nails will not shoot out in the absence of nails.
6. Strong durability: Made of high-quality materials, with precise internal structure, it can withstand high-frequency use and prolong the service life of the tool.

The Working Principle of Pneumatic Coil Nailer

1. Air source connection: Connect the pneumatic coil nailer to a compressed air source to provide the necessary power.
2. Trigger mechanism: Press the trigger, the gas flows into the cylinder, pushing the piston to move forward. Nail hitting action: the piston pushes the firing pin to hit the nail and nail it into the target material.
3. Automatic Nail Feeding: The coil nail system automatically feeds the next nail after each nail strike, ensuring continuous operation without interruption.
4. Reset process: Release the trigger, the air pressure in the cylinder is released and the piston returns to its position, ready for the next nailing.

Application Areas of Pneumatic Coil Nailer

1. Pallet manufacturing: In the assembly process of the pallet, pneumatic coil nailer is used to quickly and firmly fix the wooden boards to improve production efficiency.
2. Export box production: In the production of export boxes, the use of coil nailer to ensure that the box structure is stable, to meet the transportation requirements.
3. Crate assembly: For crates that require a lot of nailing, the coil nailer provides an efficient solution to reduce labor costs.
4. Frame making: When making wooden or metal frames, using the coil nailer can ensure the firmness of the connection points and adapt to various design requirements.
5. Furniture Manufacturing: In the furniture manufacturing process, the coil nailer is used to connect the various components to ensure that the structure is stable and meet the design requirements.
6. Carpentry projects: For various carpentry projects, such as making doors, windows, cabinets, etc., the coil nailer provides a precise and fast nailing method to enhance work efficiency.
