pneumatic framing coil nailer for crate reinforcement

The pneumatic framing coil nailer is an efficient and powerful industrial grade nailing tool designed for the rapid assembly of wood structures. It utilizes compressed air to drive rolled nails at high speeds into the wood to make a strong bond, and is capable of completing high-volume nailing jobs in a short period of time. The equipment is suitable for pallet manufacturing, export crate assembly, crate fixing, wood frame building and other scenarios that require high-strength connections.
Compared with the traditional straight framing coil nailer, the framing coil nailer can hold a larger capacity of nails, reducing the need for frequent nail replacement and further enhancing operational efficiency. Its strong penetration and stable nail fitting results make it an important tool for the woodworking, packaging, logistics and construction industries.

Technical parameters of pneumatic framing coil nailer

• Order No.: CN70
• Weight: 3.6kg
• Size: 130x315x325(mm)
• Number of nails: 300
• Using air pressure: 6 to 8kg/cm²
• Tube diameter: 8mm

Features of pneumatic framing coil nailer

1. High-capacity nail loading: Support roll nail design, a load can hold hundreds of nails, reduce the trouble of frequent replenishment, improve the efficiency of continuous operation.
2. Powerful penetration: Driven by high air pressure, it can easily penetrate hardwood, plywood, composite boards and other materials to ensure that the nails are deep and solid.
3. Fast continuous firing: Support single and continuous firing mode, applicable to different operational needs, improve production speed.



4. Depth Adjustment: Adjustable depth of nail driving, adapt to different thickness and hardness of wood, ensure the fixing effect.
5. Ergonomic design: Lightweight body, well-balanced, ergonomic handle, effectively reduce the fatigue of prolonged operation.
6. Safety mechanism: Equipped with anti-air hit device, to prevent no nails when the air hit, improve safety, to avoid damage caused by misuse.

The working principle of the pneumatic framing coil nailer

1. Air supply: Through the air pipe connected to the air compressor, compressed air into the framing coil nailer body cylinder.
2. Trigger trigger: Press the trigger, high-pressure gas to drive the piston forward movement.
3. Firing pin strike: The piston drives the firing pin to impact the nail at a high speed and nail it into the wood.
4. Nail advancement: The nail feeding system for rolled nails automatically feeds the next nail to ensure continuous operation.
5. Piston reset: After releasing the trigger, the cylinder exhausts and the piston returns to its initial position, waiting for the next trigger.

This process is completed in milliseconds time, which makes the framing coil nailer able to complete the nail loading efficiently, accurately and quickly, and improve the working efficiency.

Application areas of pneumatic framing coil nailer

1. Pallet manufacturing: For the rapid assembly of wooden pallets, to ensure a solid structure, suitable for the transportation of heavy goods.
2. Export crates: Wooden crate manufacturing in line with international standards to ensure the safety of goods in long-distance transportation.
3. Crate reinforcement: Suitable for packaging needs in agriculture, food, chemical and other industries, to enhance carrying capacity and durability.
4. Wooden frame construction: Widely used in construction, furniture, fencing, wooden houses, stage building and other carpentry projects.
5. Outdoor wood structure: Used for manufacturing gardening wood fence, wood decking, fencing, gazebo and other outdoor facilities to ensure long-term stability and durability.
