pneumatic upholstery staple gun for the construction

Pneumatic upholstery staple guns utilize compressed air as a drive source to perform a variety of nailing jobs quickly and accurately. Whether fixing wood panels in furniture manufacturing or installing thick boards or plasterboards in the decorative industry, pneumatic upholstery staple guns provide stable performance and efficient work capacity, improving work efficiency and ensuring the quality of the nailed joints.

Technical Parameters of the Pneumatic Upholstery Staple Gun

• Order No.: 9025
• Weight: 1.3kg
• Dimensions: 64x165x240mm
• Number of nails: 100
• Air pressure: 4 to 7kg/cm²
• Tube diameter: 6mm

Features of Pneumatic Upholstery Staple Gun

1. Lightweight and portable: The weight of the pneumatic upholstery staple gun is only 1.3kg, and compact design, dimensions of 64x165x240mm, easy to operate in a limited space, while reducing fatigue during prolonged use.



2. Large-capacity nail compartment: The gun can hold up to 100 nails, this capacity is particularly important for continuous work on large-scale projects, can reduce the frequency of replacing nails in the middle of the process, to avoid interruptions in production.
3. Adjustable air pressure range: Pneumatic upholstery staple gun supports 4 to 7kg/cm² air pressure adjustment to adapt to different materials and nail types. Users can adjust the air pressure according to the actual work requirements to ensure the stability and accuracy of nailing.
4. High-efficiency air hose interface: Using 6mm diameter air hose interface, this standard interface can ensure a stable air pressure supply, to ensure that the nailing process is fast and smooth.

The Working Principle of Pneumatic Upholstery Staple Gun

1. Air pressure drive: When the operator presses the trigger, the air pressure flows into the gun body through the air tube, pushing the internal piston. The push of compressed air makes the piston move quickly, releasing the nail.
2. Nail Strike: The piston pushes the nail to shoot along the barrel, striking it into the intended material with high speed and precision. The pneumatic system provides a stable and powerful impact to ensure that the nails are driven in completely without deviation.
3. Automatic reset: After each nailing session, the pneumatic system automatically resets itself, ready for the next nailing session. The efficiency of the pneumatic system allows this process to be repeated quickly and accurately.
4. Adaptive Adjustment: By adjusting the air pressure, the operator can adjust the impact force of the firing according to the hardness of different materials and the length of the nails to ensure that the results of each nailing are in line with the requirements.

Application Areas of Pneumatic Upholstery Staple Gun

1. Furniture carpentry: In the furniture manufacturing process, pneumatic upholstery staple gun is widely used for nailing wood, boards and so on. Especially in the production of sofas, chairs, bookcases and other furniture, the pneumatic upholstery staple gun can ensure that the nailing is firm and beautiful, improve productivity and reduce the fatigue of manual nailing.
2. Aluminum Tube and Spring Positioning: This tool has a great advantage in the positioning of aluminum tubes and spring components. Through its precise nailing function, it can ensure the solid combination of components in the work that requires high-precision assembly.
3. Decorative industry: In the decorative industry, pneumatic upholstery staple guns are commonly used to install materials such as thick boards and gypsum boards, especially for fixing decorative panels such as walls and ceilings. Its high efficiency allows workers to quickly complete the installation, reducing time waste and ensuring construction quality.
4. Construction industry: In construction projects, pneumatic upholstery staple guns can quickly complete the nailing of wood structures, wallboard installation and other work. By adjusting the air pressure, the tool can be adapted to different materials to improve work efficiency.
5. Mass production: For production lines or mass production operations that require a large number of nailing operations, pneumatic upholstery staple guns are essential tools. Its high efficiency and large-capacity nail compartment can ensure a long time of continuous work without frequent stops and maintenance, suitable for furniture factories, decorative companies and so on.
