printing iron drying room line chain for metal decorating system

This type of chain is based on standard short pitch precision roller chains, with enhanced performance through the addition of special attachments. The typical product structure for printing iron drying room line chains includes inner and outer support pieces to maintain chain straightness, and trellis attachments for efficient transport of articles.

Structure

• Based on standard short pitch precision roller chains with optimized structure design.
• Equipped with inner and outer support pieces to keep the chain straight.
• Features trellis installed through inner and outer attachments for item transport.
• Made from high-quality materials and produced using advanced processing technology.

Performance Advantages

• Excellent abrasion resistance and high synchronicity.
• Temperature resistance, cleanliness, corrosion resistance, and high precision.
• Reliable operation and long service life in demanding environments.

Application

• Widely used in packaging machinery, especially for drying and conveying after printing or coating on sheet metal surfaces and other industrial equipment.
• Highly efficient and reliable for post-printing or post-coating material transfer.
