stacker reclaimer chain conveyor with attachments

Stacker Reclaimer Chain with Attachment Plate is engineered for superior durability and adaptability, making it an ideal choice for demanding material handling environments. Constructed from alloy steel and processed with advanced heat treatment, this chain delivers outstanding wear resistance and long service life, even under high load and harsh conditions.

Structural Features

• Available in a wide range of chain pitches (e.g., 250, 270, 315, 400mm) to suit different working requirements.
• Attachment types include outer straight high plate, welded outer plate, and outer curved plate, enhancing adaptability to varied environments and material characteristics.
• Specifications cover roller diameters from 26.5mm to 120mm, chain plate thickness and width from 3mm to 12mm, and diverse pin diameters, ensuring performance and reliability across applications.
• Customizable design meets specific load, capacity, and operational needs.

Key Benefits

• Exceptional wear resistance for long-term stable operation in high-load, abrasive environments.
• Diverse specification options for optimal adaptation to working conditions and material types.
• Enhanced working efficiency and safety due to robust construction and specialized attachment designs.
• Reliable performance handling slurry, granular, and bulk materials.

Applications

• Cement production
• Pulp and paper industry
• Sugar manufacturing
• Chemical processing
• Other material handling and bulk transport operations

Stacker Reclaimer Chains with Attachment Plates are the trusted solution for industries requiring high-capacity, durable, and efficient material handling. Their versatile design and superior wear resistance ensure safe and continuous operation in complex production environments.
